Water Treatment Tank

Name: Water Treatment Tank
Brand: Delsol Engineering India Pvt. Ltd
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Water Treatment Tank Specification

Condition
NEW

Capacity
100 To 120000 Ltr/hr

Tolerance
+ - 5 Millimeter (mm)

Usage
Industrial

Height
300 To 3600 Millimeter (mm)

Product Type
Tank

Weight
300 To 30000 Kilograms (kg)

Color
RAL 7035, Black, Appel Green

Length
1000 To 12000 Millimeter (mm)

Width
300 To 2200 Millimeter (mm)

Water Treatment Tank Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
25 Days

Main Domestic Market
All India

Water Treatment Tank About

What is a Water Tank?

A Water Tank is a container used to store water fordomestic, industrial, agricultural, or firefighting applications. It can bemade of various materials and designed for ground, elevated, or undergroundinstallation.

Types of WaterTanks

Type	Description	Use
Overhead Tank	Installed on rooftops	Residential, commercial
Underground Tank	Buried below ground	Firefighting, rainwater harvesting
Ground-Level Tank	Installed on slab	Industrial plants, irrigation
Pressurized Tank	Maintains water pressure	Industrial systems
Modular Panel Tank	Bolted panels (SS/FRP)	Large capacity, quick install
Mobile Tank	On trailer or wheels	Temporary water supply

Materials Used

Material	Properties	Usage
Stainless Steel (SS304/SS316)	Hygienic, corrosion-resistant	Pharma, food, RO systems
Mild Steel (MS) + Epoxy Coated	Strong, economical	Industrial water
Plastic (HDPE/LLDPE)	Lightweight, cheap	Domestic storage
FRP/GRP	Non-corrosive, lightweight	Coastal, chemical industries
Concrete	Durable, static	Underground and large reservoirs

Technical Specifications (Typical)

Parameter	Value
Capacity	100 liters 1,00,000+ liters
Shape	Cylindrical, rectangular, square
Orientation	Vertical or horizontal
Material	SS304, SS316, HDPE, FRP
Wall Thickness	2 mm to 20 mm
Inlet/Outlet	" to 4" BSP/NPT
Accessories	Float valve, vent, level gauge, manhole
Finish	Matte / mirror / epoxy / UV-resistant

Design Options

Cylindrical Vertical Tank (most common)
Rectangular SS Tank
Insulated Tank (PU foam or mineral wool)
Partitioned Tank (for two water types)
Custom fittings (drain, overflow, spray balls)

Testing &Standards

Hydrostatic Test (UG-99 for SS pressure tanks)
Weld Dye Penetration Test
Leak Test / Vacuum Test
Standards:

IS 10500 (Drinking Water)
ASME Sec VIII Div 1 (for pressure tanks)
GMP/FDA compliant for food/pharma tanks

Advantages

Safe and hygienic water storage
Available in various materials and sizes
Low maintenance
Long lifespan (especially SS/FRP)
Customizable for all industries

Limitations

Plastic tanks degrade in sunlight
MS tanks need internal coating
Large tanks require proper foundation
FRP tanks need skilled fabrication

Applications

Domestic Drinking, bathing, flushing
Industrial RO/DM water, coolant tanks
Pharmaceutical WFI, purified water storage
Agriculture Irrigation and rainwater harvesting
Fire Fighting Overhead/underground reservoirs

Example Required for Quotation:

Please share any of the following to customize:

Capacity: (e.g. 1000 L, 5000 L)
Material: SS304 / SS316 / MS
Mounting: Ground / Roof / Underground
No. of Inlets/Outlets
Application: Drinking / process water / irrigation

Customizable Capacity and Dimensions

Choose precisely what you need: our tanks handle from 100 to 120,000 liters per hour, with adaptable lengths, heights, and widths. This flexibility allows tailoring to your factory's specific volume and space requirements, ensuring a seamless fit and efficient water processing.

Engineered for Industrial Performance

Our tanks are meticulously fabricated with an impressive tolerance of 5 millimeters, delivering reliable operation in demanding industrial environments. Constructed for heavy-duty performance, they support a variety of industrial water treatment applications with long-term structural integrity.

Durable Finishes, Multiple Color Choices

Both functional and visually adaptable, our tanks are available in RAL 7035, black, and apple green. This versatility ensures compatibility with your facility's aesthetic or operational safety codes while maintaining robust, corrosion-resistant surfaces.

FAQ's of Water Treatment Tank:

Q: How do I select the right water treatment tank size for my facility?

A: Consider your facility's peak water processing needs and space constraints. Our tanks range from 100 to 120,000 liters per hour, with dimensions tailored from 1000-12000 mm in length and 300-2200 mm in width, so you can choose the exact capacity and fit required for your application.

Q: What is the main benefit of using this industrial water treatment tank?

A: The primary benefit is efficient, reliable, and high-capacity water treatment suitable for various industrial applications. With precise construction and a tolerance of 5 mm, these tanks ensure consistent water quality and help optimize your purification process.

Q: Where are these tanks manufactured and supplied from?

A: All our water treatment tanks are fabricated, manufactured, and supplied from India, ensuring locally sourced quality and streamlined distribution for clients across the nation.

Q: What processes are these tanks designed to support?

A: These tanks are engineered for industrial-scale water treatment processes including filtration, sedimentation, and chemical dosing. Their robust build accommodates both standard and specialized treatment operations.

Q: When should I consider upgrading my industrial water treatment tank?

A: Upgrade when your existing system no longer meets your facility's processing capacity, efficiency, or regulatory standards. Our tanks can accommodate expanded flow rates and provide enhanced durability for demanding modern operations.

Q: How does the 5 millimeter tolerance impact the tank's performance?

A: A tight tolerance of 5 mm ensures precise fabrication, resulting in reliable connections, minimal leakage, and optimal integration with other system components for stable and efficient operation.
